Description
Aluminium hardtail, sporting easy to accelerate and nimble 27.5″ wheels, our more comfort-focused geometry, 100 mm of front suspension and a double chainset setup, giving you plenty of gears to choose from and lots of comfort and control
FEATURES
- Double butted aluminium frame with 27.5″ wheels
- Less aggressive and more upright geometry for maximum control and comfort
- Shimano 8-speed drivetrain with double chainring setup
SPECIFICATIONS
- Intended Use- Mountain
- Wheel Size- 27.5″
- Braking System- Power Hydraulic Brake System
- Frame Material- Aluminium
- Fork Material- Aluminium
COMPONENTS
- Frame- BIG.SEVEN TFS III material: aluminium 27.5×2.25″ max. wheelsize 135x9mm axle standard BSA bottom bracket standard
- Fork- SR Suntour XCT30 HLO Coil 100mm suspension travel Lockout 27.5×2.25″ max. wheelsize
- Bottom Bracket- FSA TH-7420ST-W, Cartridge Bearing
- Chain- Sunrace M84
- Crank- Shimano TY301 42-34-24 teeth 170 mm-XS/S, 175 mm-M/L
- Shift Levers- Micro Shift TS39-L / Micro Shift TS39-8R
- Cassette- Sunrace CSM668 11-32 teeth 8 speed
- Front Derailleur- Shimano FD-TY700
- Rear Derailleur- Shimano RD-M360
- Grips/Bartape- MERIDA EC
- Handlebar- MERIDA CC material: aluminium 690mm width 15mm rise
- Stem- MERIDA CC material: aluminium 31.8mm diameter 6° stem angle 70 mm-XS/S, 80 mm-M, 90 mm-L
- Saddle- MERIDA Sport comfort
- Seatpost- MERIDA CC material: aluminium 30.9mm diameter 15mm setback
- Front Brake- Power DS100 2 piston hydraulic disc brake
- Rear Brake- Power DS100 2 piston hydraulic disc brake
- Front Wheel- MERIDA CC, Shimano TX505 100×9 mm width front hub 32 spoke holes Centerlock
- Rear Wheel- MERIDA CC, Shimano TX505 135x9mm width rear hub 32 spoke holes Centerlock
- Tire- MERIDA K1080 27.5×2.2″ wire
- Pedal- VP VPE-891
